Hello, I have a new generator speced above, and need to make the MODBUS RTU connection, but cant find where to land the cable. I have the IOM, it has a terminal strip diagram with terminals, but doesnt give the location of the strip. I looked in the right side panel, where it seems all the terminal strips are, but didnt see exactly what I expected. I did find a connection labeled 'modbus', except it already has wires landed on both sides of the terminal strip.and the wires seems to be connected to internal devices as far as I can tell. Heres hoping someone can help. Thanks in advance.

• Emcp 2 Manual

Caterpillar EMCP3 MODBUS communication. Please guide me to where I can find the MODBUS addresses for the alarms. Or do they have to be programmed in the EMCP.

Emcp 2 Manual

Overview Producing reliable power from 2000 kVA to 2500 kVA at 50 Hz, our 3516B diesel generator sets are made to match your mission critical, continuous, standby and prime applications. Each meets ISO 8528-5 transient response requirements and accepts 100 percent rated load in one step. Depending on the model, our 3516B generator sets are designed for either low fuel consumption or low emissions — it's how we're helping you power responsibly.

Ensure you have a non-stop power supply with our integrated control system, including Cat® UPS, ATS and switchgear, and know your fleet status with its on-site and remote monitoring options. Our EMCP 4.2 control panel, with a user-friendly interface, combines all your management and diagnostic tools. Equip your generator sets with what they need to operate to your standards with our broad range of accessories and bolt-on system expansion attachments.

Find flexible packaging options to work with your environmental conditions. Our 3516B generator sets were designed to take on power challenges — like yours. Engine Specifications Engine Model 3516B TA, V-16, 4-Stroke Water-Cooled Diesel 3516B TA, V-16, 4-Stroke Water-Cooled Diesel Compression Ratio 15.5:1 15.5:1 Aspiration TA TA Governor Type Adem™3 Adem™3 Fuel System Electronic unit injection Electronic unit injection Air Inlet Single element canister style with service indicator Single element canister style with service indicator Bore 6.69 in 170.0 mm Displacement 4764.73 in³ 78.0 l Exhaust Flange Size 203.2 mm (8.0 in) 203.2 mm (8.0 in) Stroke 8.46 in 215.0 mm. 3516B (50 Hz) with Upgradeable Package Standard Equipment Air Inlet System. Air Cleaner; single element canister type Control Panels.

EMCP 4.2. Emergency stop pushbutton.

24 Volt DC operation. Environmental sealed front face.

Text alarm/event descriptions. Generator mounted - rear facing. Generator set packages include Caterpillar' s Voltage Regulator. IVR includes reactive droop capability, 3-phase voltage sensing, KVAR/PF modes, RFI suppression, min/max exciter. Cat Diesel Engine The four cycle Cat diesel engine combines consistent performance with excellent fuel economy and transient response that meets or exceeds ISO 8528-5. The engines have been designed and built for a wide range of applications and can be optimized for low fuel consumption or low emissions. The engines feature a reliable, rugged, and durable design that has been field proven in thousands of applications worldwide from emergency standby installations to continuously operating power plants.
