Overview for the Sokkia SHC250 Data Collector With the help of advanced handheld field computers like the Sokkia SHC250 Data Collector, surveyors can record accurate land measurements simpler and faster. Integrating a Windows operating system, Bluetooth, Wi-Fi and touchscreen, this field controller allows you to work in remote locations and harsh weather conditions. This advanced handheld field computer is battery powered, portable, and equipped with a microprocessor, internal memory for data storage and wireless features for data transfer.
With built-in keypad, LCD display and Windows operating system, it is used to transfer collected data from total stations or GPS systems to office software programs. Wireless Communication Compact and lightweight, the Sokkia SHC250 Data Collector features a sunlight readable LCD touchscreen display and a variety of communication and connection capabilities such as a built-in Wi-Fi and Bluetooth capabilities for cable-free connection with other land surveying equipment and personal computers. Whether you use CompactFlash (CF) or SD cards, a USB stick or direct USB connection over Microsoft’s ActiveSync, this device offers multiple options in transferring your survey or stakeout data with ease. Windows OS Providing a user-friendly interface through the Windows Mobile 6.5 operating system, even inexperienced surveyors can take advantage of the SHC250.
It runs the mobile version of Microsoft Office programs, such as Word, Excel, PowerPoint and Outlook. You can also surf the web via Internet Explorer and play audio and video files using Media Player. Memory The combination of 806MHz high-speed processor and 256MB RAM dramatically speeds up all data collection and calculations on this device. In addition, this portable surveying field controller has 1 GB of onboard memory for storing applications and other field data. Rugged Design With an IP-66 rating, this field controller will keep your data safe from sand, dust or water.
It also works in scorching heat or subzero job site temperatures – places you could not take a conventional-grade handheld computer. Field-replaceable Battery For a continuous survey process, this Sokkia data collector has a rechargeable and removable Li-ion battery that operates up to 10 hours.
Focusing on the specific needs of the conventional surveying market, the Spectra Precision brand. Optical total stations, data collection hardware, field.
It can be easily replaced at the worksite, eliminating down time due to battery drain. This package comes with a stylus pen, USB cable, hand strap, screen protector, rechargeable Li-Ion battery, AC power plug and a 1-year manufacturer’s warranty and integrates with a variety of Sokkia and Topcon field software.
Overview for the Sokkia SHC2500 Data Collector The Sokkia SHC2500 Data Collector with Spectrum Survey Field (SSF) Complete software satisfies surveyors and engineers requiring precise land measurements with universal controller ideal for robotic total stations. This rugged handheld field computer combines the functionality of an alphanumeric keyboard, a Windows operating system, surveying software, a digital camera, wireless communications and networking capabilities to gather accurate field data even in extreme weather conditions. The Sokkia SHC2500 has a microprocessor, internal memory, wireless features and Windows OS. This device is lightweight and battery powered, making it very easy to carry and use in the field.
In conjunction with total stations or GPS systems, it can transfer collected data to a personal computer for viewing, analyzing and editing. Bluetooth Robotic Capabilities With a full alphanumeric keyboard and built-in Bluetooth technology, the Sokkia SHC2500 is the ideal robotic total station controller. In fact, you can connect this field controller to long-range Bluetooth devices from Sokkia like the new.
Touchscreen and Full Keyboard For fast and accurate data entry, the large keys are easy to operate even with gloved hands. It also features an LCD touch screen display that provides excellent visibility, even in direct sunlight. Connectivity This portable data collector has a built-in Wi-Fi so you can use it in a hotspot area to surf the Internet, check weather, e-mail files back to the office and more. It also has a 5-megapixel camera that doubles as a bar code scanner and a USB miniport for transferring files through a USB stick or Microsoft’s ActiveSync connection. Memory and Windows OS Loaded with all the speed and memory needed to accelerate data collection, the SHC2500 comes standard with a 624MHz XScale processor, 256MB RAM and 2GB flash storage memory. It is also equipped with a Windows CE.NET 5.0 operating system that provides a modern interface, processes higher resolution images and adds compatibility with other application software. The simple and familiar functionality leads to a short learning curve because popular mobile versions of Microsoft Word, PowerPoint, Excel and Adobe PDF Reader are available on this field surveying data collector.
Sokkia Spectrum Survey Software Spectrum Survey Field Complete on-board is the ultimate field software with all the features and functions of SSF Basic, PRO, RTS and GPS+. It speeds up surveying with its superior data management that gives the freedom to create, edit, upload and download field data with ease. This on-board data collection software allows you to connect to Sokkia’s entire field sensor portfolio. It stores the full configuration settings for each device and recalls them with just a single tap on the interface, allowing you to easily choose the right tool for the job.
Run Third-Party Applications In addition, this field controller software enables the SHC2500 to run a number of third party applications, such as generic mapping programs, GPS navigation and roading functions. With its large graphical interface, you can simply touch the icons on the screen or use a stylus pen.
Spectrum Survey Field
SSF Complete also supports all major field data file formats and it works with Photo Notes, which automatically integrates field measurements into your captured images. Rugged Design Don’t worry about your survey data getting corrupted or erased because the entire field controller is sealed and water resistant. With an IP-67 rating, it is submersible in up to 3 feet of water for 30 minutes and can withstand sand or dust for at least 8 hours of operation. The Sokkia SHC2500 also meets rigorous military standard for extreme temperatures, shock and drops from up to 4-feet high! Its double wall case construction seals the device against environmental hazards, enabling you to use it even in bad weather. Long-lasting Battery Life With two 2500mAH Li-ion rechargeable batteries, battery performance on this Sokkia data collector can be as high as 50 hours!
But power-hungry features may alter the result, for instance, a typical power drain from a Bluetooth connection to a GPS receiver will limit the operation time for 24 hours. The batteries are also removable so you can replace them in the field without turning off the device.
Spectrum Survey Field Reference Manual
In addition, overcharging will never be an issue because the SHC2500 has internal temperature monitors that prevent any unexpected high temperature issues. This Sokkia SHC2500 exclusive package comes with a carrying bag, stylus pen, USB download cable, USB flash drive adapter, hand strap, screen protectors, two rechargeable batteries, charger and 1-year manufacturer’s warranty.
