CNCSHAPE (Shape recognition preview positioning control: Patent granted). Combining with the preview positioning control function, high performance contouring control with remarkable data traceability can be realized. Controls the two modes for rough finishing and fine finishing. Separate adjustment of each axis acceleration or deceleration according to each axis inertia. Pre-reads the data of 1800 successive blocks of tool path according to blocks of very short line of tool path. Equipped with fluent control function for smooth interpolation of uneven point-to-point data.
When processing successive blocks of short line of tool path at high speed, geometrical errors caused by impacts at corners, or by a delay in the servo system can be eliminated, thus assuring precise machining operations.
Tosnuc Manuals Instruction Manual and User Guide for Tosnuc. We have 1 Tosnuc manuals for free PDF download.
BMC 800 from Toshiba Toshiba Tosnuc CNC Training This has got to be one of my favourite controls. Call me a geek but I get really excited about this kind of stuff.
Below is the 888 control. (The 666 is a bit of a devil to programme) Considering how old these controls are they are packed with great functions. The editing is a dream. It has a clipboard, well it has loads of clipboards, so you can keep bits of code you use often on different clipboards.
When you need em you can quickly call them out and insert into your programme. This control is really well thought out you can do things like adding spaces to all your code at the push of a button and likewise take them out again. The other thing is it has these funny dice icons.
You can assign keystrokes to each dice so anything you do on a regular basis can be stored and used at one press of a button. The playing card icons are assigned to screen window arrangements.
Again at the press of a button you can have your programme prove out page laid out just how you like it. You can really customise this control and make it your own.
MDI (Manual Data Input) So for example something you regularly use in MDI like move to zero return you could let it record as you clear the MDI screen and input the code. Once recorded this will be one press of a button (or a roll of the dice) Anyone for poker? I could bang on for ages about this control. Why not I think I will? It’s got corner rounding and chamfering. G1 X50.: R20. This code could be putting corners on a square.
You just programme point to point. Let’s make em chamfers. G1 X50.: C20. It’s even got a built in floppy disc. I think at this time on a Fanuc control you needed a degree in computer science and a skilled electrician to connect up and get data out of a machine.For our younger viewers a floppy disc was like a squashed memory stick.
Toshiba Tosnuc 888
Oh and no zero return shit! Yes you just turn it on. How easy is that. Yes it is ISO programming that is G code programming is definitely not easy to learn. Unfortunately we’re kind of stuck with it because it is what everybody knows. Anyway on this control there are lots of extra cycles like G12 which is full circle milling also found on Haas controls.
This cycle can rough and finish a circular pocket. You could just use it to mill a full circle, it uses a tangential approach so there are no entry and exit marks.
This circular pocket also uses cutter compensation. So you don’t have to worry your sweet little head about it’s all included. It’s like one of those holidays in Spain where you can get drunk all day and eat as many burgers as you want, all inclusive.
In case you don’t know what tangential infeed it. It’s a sexually transmitted disease. Actually it just means you approach the circle in a circular motion. Great thing is you don’t get a line where the cutter first approaches the part. There are face milling cycles and drill pattern cycles and loads more. It can even make a cappuccino.
This is a high end top quality machine so it comes all singing all dancing. You get Toshiba Tosnuc Macro programming which allows you to do all kinds of clever shit. You can alias it to G codes and M codes to create your own cycles.
